Roland CAMM-1 GR-540 Large Format Cutter
Roland CAMM-1 GR-540 Large Format Cutter

Product Development Inc Exclusive
Roland GR-540 Complete Package
Lease for $125 Month - Apply Now

Retail Price: $5,995.00
Open Box Sale Price: $5,495.00

Open Box Unit - 1 Year Factory Warranty
1 Available Ready To Ship
FREE STAND
You save $500.00!

Buy Now

Request Quote
Easy to use online form to choose your
options and request a quote.


Open box unit was used at a tradeshow and has less then 1 hour of use, will ship in original factory box.

Includes - 1 Year Factory Warranty, Stand, Online Training, and Gold Level Tech Support.

Roland Authorized Dealer for all 50 US States
Serving Government, Business, Education, Individuals


Availability: Usually Ships in 24 Hours
Product Code: ROLAND-GR-540

Description Features Technical Specs

Overview
Roland CAMM-1 GR-540 Large Format Cutter
The Roland CAMM-1 GR-540 large format cutter is a powerful, easy-to-operate device. Packed with advanced and versatile new features, the Roland CAMM-1 GR-540 is designed for a whole new level of sign, apparel, vehicle graphics and packaging production. The new Roland CAMM-1 GR-540 large format cutter integrates with Roland software and print devices, as well as other manufacturers' software and printers. Featuring Roland’s famously precise and reliable CAMM-1 technology, the CAMM-1 GR-540 cutter far exceed the needs of today’s graphics professionals with outstanding media versatility, speed, accuracy, and state-of-the-art cutting features.
Total Control
With the Roland CAMM-1 GR-540 large format cutter you can accelerate your production while ensuring precision and reliability with features that include the fastest cutting speed in its class at 58.5 in/s (1,485 mm/s) and the industry’s most precise and dependable cutting motor with up to 600 gf of down force. An LCD control panel and other advanced features give users complete control. In addition to smart new pinch rollers and "on-the-fly" pen force adjustment, the Roland CAMM-1 GR-540 cutter enable users to manually adjust blade offset values for added cutting precision, store up to 2MB of preset cutting data, and easily follow the status of each cutting job with a handy LED status light. The Roland CAMM-1 GR-540 large format cutter also feature an Ethernet port to connect your cutter to a network for a streamlined workflow.
Over Cutting
The Roland CAMM-1 GR-540 cutter feature overcutting (tangential emulation) of .04 inches (1 mm) to ensure sharp edges. Overcutting corners is the process in which the blade travels past the cut line before the blade is lifted, turned and rotated toward the new cut direction in advance of the new cut line. The result is sharp, clean cuts with easy to weed corners.
Perforated Cutting
A new blade holder features two blade positions with the rear position designed for perforated cutting. A specially designed cutting groove in the platen enables the blade to cut clean and avoid unwanted damage to your blade. This makes the Roland CAMM-1 GR-540 perfect for creating pop-out decals and packaging prototypes.
Vehicle Graphics
Create contour cut graphics, paint/sandblast stencils, pinstriping and more for cars, trucks, jet skis, and other vehicles. With incredibly powerful cutting features, GR cutters handle a huge range of thick and thin media with ultimate precision and ease. It's the ideal machine for both large format boat and airplane graphics, and for quick window tinting and bumper sticker jobs.

Buy Film Design Pro and have every vehicle model at your fingertips - create thousands of window tint templates and film patterns. Contact us for a quote.
CutStudio Software Included
Roland CutStudio allows designers to quickly and easily enlarge, reduce, re-position, rotate and mirror images. BMP, JPG, STX, AI, and EPS file formats are all supported. The latest version includes new scaling and cut-layer outputting functions. Roland CutStudio software combines easily with other industry-standard software. Plugins for Adobe Illustrator (Mac and PC) and Corel Draw (PC) are also available as additional web downloads.
Materials
The Roland CAMM-1 GR-540 large format cutter makes it fast and easy to cut a wide variety of materials. The Roland CAMM-1 GR-540 large format cutter handles Cardboard, Corrugated e-flute, Heat Transfer Material, Diamond Grade Films, Sandblast Mask, Vinyl Films, Window Films, High Intensity Reflective Films.
Roland GR-540 Features:
  • Easy to Operate
  • Works With Your Printer
  • Overlap Cutting (up to 10x)
  • Fastest Cutting Speed In Its Class
  • Powerful Cutting Motor
  • Unmatched Cutting Strength
  • Integrated Media Holder (rolls up to 88.5 lbs)
  • Cutting Groove To Prolong Blade Life
  • Quadralign Optical Print/Cut Registration For Exact Print Then Cut Workflow
  • Perforated Cutting
  • Ethernet and USB 2.0 Interface
  • 3 Year Trouble Free Warranty
Roland GR-540 Technical Specs:
  • Loadable Material Widths: Max 60" Min. 6"
  • Max Cutting Area: 55" W x 984" L
  • Max Cutting Speed: 1,485 mm/s
  • Max Cutting Media Thickness: Up To 0.04"
  • Cutting Force: 20- 600gf
  • Mechanical Resolution: 0.005 mm/step
  • Computer Interface: USB/Ethernet
  • Computer OS: Win 10, 8, 7
  • Computer OS: 32 or 64 Bit
  • Power: 110V/0.7A
  • Dimensions With Stand: 76" W x 30" D x 47"H
  • Weight With Stand: 192 lbs.
Roland GR-540 Materials:
  • Vinyl
  • Paint Mask
  • Twill
  • Frosted
  • Corrugated
  • Heat Transfers
  • Sandblast Material
  • Card Stock
  • Glitter
  • Labels
  • Sign Vinyl
  • Rhinestones
  • Window Films
  • Metallic
  • Paint Mask
  • Reflective Vinyl
  • Magnets
  • Card Board
  • Colored
  • Diamond Grade
Roland GR-540 Applications:
  • Jeans
  • Backpacks
  • Helmets
  • Auto Restyling
  • Banners
  • Polo Shirts
  • Paint Masking
  • Signage
  • Stickers
  • Decals
  • Graphics
  • Clear Paint Film
  • Jackets
  • Trade Show
  • Windows
  • Jerseys
  • T-shirts
  • Magnets
  • Glass Display
  • Sports Team Bags
  • Restaurant
  • Mirrors
  • Soccer Balls
  • Footballs
  • Softballs
  • Baseballs
  • Basketballs
  • Window Tint
Compare with other Roland Vinyl Cutters Here
Award Winning Dealer

Product Development Inc has been selling and supporting Roland equipment for over 15 years. We have won multiple awards for both sales and service. Our company started as a design firm/model shop using CAD and 3D prototyping equipment like 3d printers and cnc machines to design and build products for our customers. We made a transition over 12 years ago to focus on selling equipment to engineers and others who create. We sell Roland equipment to all companies, individuals, schools and universities. We ask that you please consider us when making a purchasing decision, we have the knowledge and experience to make you successful. See who trusted us to help them find a solution for their needs.

Introduction Video
We have additional Introduction and Training Videos for the Roland GR-540.
Select the Playlist in the upper left corner to choose the other videos.
Applications
Roland CAMM-1 GR-540 Applications:
  • Jeans
  • Backpacks
  • Helmets
  • Auto Restyling
  • Banners
  • Polo Shirts
  • Paint Masking
  • Signage
  • Stickers
  • Decals
  • Graphics
  • Clear Paint Film
  • Jackets
  • Trade Show
  • Windows
  • Jerseys
  • T-shirts
  • Magnets
  • Glass Display
  • Sports Team Bags
  • Restaurant
  • Mirrors
  • Soccer Balls
  • Footballs
  • Softballs
  • Baseballs
  • Basketballs
  • Window Tint
Brochure
Roland GR-420 Brochure

Want to learn more about the Roland GR-540?

Download the Roland GR-540 Brochure.

Inside you can learn about:
  • Roland CAMM-1 GR-540 Features...
  • Roland CAMM-1 GR-540 Specifications...
  • Roland CAMM-1 GR-540 Options...
  • Roland CAMM-1 GR-540 Capabilities....
  • And a whole lot more...
Roland GR-540 Brochure
Ask Expert About Roland Vinyl Cutters
