Roland LG-300 UV Large Format Printer Cutter
Roland LG-300 30" TruVIS UV Large Format Printer Cutter

Product Development Inc Exclusive
Roland LG-300 Complete Package
Lease for $464 Month - Apply Now

Retail Price: $22,195.00
Special Package Price Available

Configure and Price
Build your custom package and get the price

Have questions? ASK AN EXPERT

Roland Authorized Dealer
Serving Government, Business, Education, Individuals
Roland does not sell direct to customers


Availability: Usually Ships in 24 to 48 Hours

DESCRIPTION FEATURES TECHNICAL SPECS

Roland LG-300 Overview Section
Roland LG-300 Overview Picture

Roland LG-300 Large Format UV Printer Cutter

The Roland LG-300 is a 30" UV LED printer/cutter engineered for production-focused shops that need UV quality with roll-media flexibility. Running ECO-UV5 ink from high-capacity 750ml pouches, it keeps costs down and output moving, delivering sharp, fast-drying prints on everything from window graphics and backlit films to stickers, signage, and specialized wall coverings. Start a UV print business, step up from eco-solvent, or add premium specialty output to an existing operation. The LG-300 pairs professional UV capabilities with the integrated contour cutting TrueVIS is known for. Two-year warranty included.


Roland LG-300 Large Format UV Printer Cutter Roland LG-300 UV Printer Cutter
The Roland LG-300 handles media widths from 7.2" to 30" with a maximum print/cut width of 28.9". Media thickness up to 39.3 mil (1.0 mm) for printing, 15.7 mil for cutting. Integrated UV-LED curing, a 7" color touchscreen, built-in take-up unit, one-touch auto media calibration, and perforated sheet cut for unattended long runs. High-speed mode delivers up to 229 sqft/hr in CMYK.

Roland LG-300 VersaWorks Printing Software Roland LG-300 VersaWorks 7 Printing Software
VersaWorks 7 is included with the LG-300 and manages the complete UV print-and-cut workflow. Auto-generate White and Gloss layers with Special Color Plate Generation, extract cut lines from PDF files without switching software, and use the 500+ texture preset library to build tactile effects and specialty finishes into media output. Built-in color tools make brand matching and consistent results straightforward across jobs.

Roland LG-300 Extension Table Roland LG-300 Extension Table
The optional ET-30 Extension Table provides a firm platform for printing on semi-rigid media and folding carton stocks up to 1.0 mm thick through the LG-300. It stabilizes card stock during printing to reduce skew and misalignment, making it well-suited for packaging prototype development and multi-iteration design workflows.

Roland LG-300 Take Up Unit Roland LG-300 Take Up Unit
The LG-300 features a built-in take-up unit engineered for robust, accurate, and effortless operation, enabling long, unsupervised print runs without constant monitoring. An adjustable end-cap accommodates various media tube lengths, while the one-touch media holder allows for quick, hassle-free loading. Versatile and durable, it's compatible with a wide range of materials, from delicate thin films to heavy-duty canvas, maximizing productivity and workflow efficiency.

Roland LG-300 BOFA PrintPRO Air Filtration Roland LG-300 BOFA PrintPRO Universal
The BOFA PrintPro Universal air filtration unit is recommended alongside the LG-300 to maintain a clean and comfortable environment during UV printing. Its universal design integrates easily with wide-format UV printers and fits into a variety of shop configurations.

Roland LG-300 Warranty and Support Roland LG-300 Warranty and Support
The Roland LG-300 carries Roland DGA's industry-leading two-year warranty, strong coverage that reflects the production-grade build of the printer. Expert support through Roland DGA Care is available throughout your ownership, and Extended Service Contracts are available through your authorized Roland DGA dealer.

Roland LG-300 Configure and Price Roland LG-300 Lease Financing Roland LG-300 Request A Sample Roland LG-300 Ask An Expert
Roland LG-300 Introduction Video Section
We have additional Videos for the Roland LG-300.
Select the Playlist in the upper left corner to choose the other videos.
Roland LG-300 Details Section
Roland LG-300 Features:
  • Affordable
  • Easy to Operate
  • Quiet Operation
  • Clear Ink for 3D Effects
  • White Ink Recirculation
  • Optional Rigid Media Accessory
  • Includes New VersaWorks 7 Software
  • 2 Year Trouble-Free Warranty
Roland LG-300 Technical Specs:
  • Printing/Cutting Width: 28.9"
  • Media Width: 7.2" to 30"
  • Media Thickness: 1.0mm (39mil)
  • Cutting Force: 30 to 500 gf
  • Computer Interface: Ethernet
  • Dimensions: 80.3"W x 29.5"D x 55.6"H
  • Weight: 371 lb (168 kg)
  • Power: AC 100 to 240V, 5.7 or 2.6A
Roland LG-300 Materials:
  • PE
  • PVC
  • Foils
  • Vinyl
  • Paper
  • BOPP
  • Textiles
  • PET Film
  • Cardstock
  • Cardboard
  • Static Cling
  • Semi Rigids
  • Backlit Film
  • Matte Paper
  • Banner Vinyl
  • Gloss Canvas
  • Matte Canvas
  • Natural Leather
  • Synthetic Leather
  • Transparent Films
Compare with other UV Printer Cutter Here
Roland LG-300 Applications Section
Roland LG-300 Applications Picture

Roland LG-300 Applications:
  • Boxes
  • Labels
  • Decals
  • Photos
  • Badges
  • Backlit
  • Awards
  • Sleeves
  • Fine Art
  • Banners
  • Signage
  • Stickers
  • Pouches
  • ID Plates
  • Packaging
  • Stationary
  • Wallpaper
  • Asset Tags
  • Tradeshow
  • Shrink Film
  • Decorations
  • Home Décor
  • Wall Graphics
  • Control Panels
  • POP & Displays
  • Clear Packaging
  • Instruction Plate
  • Rapid Packaging
  • Premium Design
  • Point of Purchase
  • Window Graphics
  • Personalized Items
Roland LG-300 Brochure Section
Roland LG-300 Brochure

Want to learn more about the Roland LG-300 Large Format UV Printer Cutter?

Download the Roland LG-300 Brochure.

Inside you can learn about:
  • Roland LG-300 Features...
  • Roland LG-300 Specifications...
  • Roland LG-300 Options...
  • Roland LG-300 Capabilities....
  • And a whole lot more...
Roland LG-300 Download Brochure
Roland LG-300 and PDI3D About Us Section PDI3D Award Winning Dealer

Have questions about the Roland LG-300 Large Format UV Printer Cutter?

We are more than a website. We are real people who have been using the Roland UV Printer Cutter for over 25 years.

Here are some things we can help you with... Roland LG-300 Ask an Expert Details
  • Discuss your application to make sure it's a good fit.
  • Discuss materials, part sizes, and print area.
  • Send you a sample kit of prints made with the machine.
  • Print samples on your products.
  • Help you choose the accessories that you need.
  • Put together a special package price for your specific application.
