INTAMSYS FUNMAT PRO 610 HT 3D Printer Features
INTAMSYS FUNMAT PRO 610 HT Printer
INTAMSYS introduces the FUNMAT 610 PRO HT, an all-in-one solution among the very few 3D printers able to print high-performance materials such as PEEK, ULTEM (PEI), and more.The INTAMSYS FUNMAT 610 PRO HT is designed to 3D print functional parts and for continuous low volume production. Thanks to its smart design and low noise emission, the INTAMSYS FUNMAT 610 PRO HT is suitable for both factory and office environments.
Support Material
Each level of plastics (PLA, engineering plastics, high-performance), INTAMSYS offers corresponding support materials: SP1000 for PLA, SP2000 for engineering plastic (PA, PC+CF, PC ABS etc), and SP5000 for high-performance, functional materials like PEEK, PEKK, PEEK+CF, PEI, PPSU, and more. All of the support materials are soluble or breakaway, so users can achieve smooth support surface. The INTAMSYS Funmat 610 PRO HT also features a heated filament chamber in order to avoid filament moisture absorption during the printing process.
High Temperature
The high-temperature capacity of the INTAMSYS FUNMAT 610 PRO HT allows it to 3D print more than 20 types of functional materials, and is designed for ease-of-use with features such as automatic leveling to ensure tolerances and accuracy, a jam warning to save on wasted time of the printer running uselessly, an absence filament warning for knowing when the filament roll has finished, and power failure recovery to avoid having to start a print over because of a system failure. Coupled with the enhanced and intuitive user experience also includes a 10-inch Smart Touch Panel, as well as advanced connectivity choices between WiFi, USB, and ethernet. With all of these capabilities it won't matter how experienced the users are, they can quickly master the INTAMSYS Funmat 610 PRO HT.
Designed for Professional Users
Designed for professional and industrial users like you, the INTAMSYS FUNMAT PRO 610 HT 3D printer is positioned above common 'concept modeling' desktop 3D printers with the intention of allowing engineers and creators access to material types with properties that allow functionality and capability not available before. The INTAMSYS FUNMAT PRO 610 HT features a spacious build chamber and 24" X 20" X 20" (610mm x 508mm x 508mm) in build volume. The advanced thermal system comprises a 572°F (300°C) constant temperature chamber, 572°F (300°C) heated build plate and 932°F (500°) high-temperature extruder with all-metal hotend. The Funmat 610 PRO HT is capable of printing over 14 types of high-performance and engineering-grade thermoplastics at larger dimensions. Start building large-size and robust production parts in a variety of materials today on the Funmat 610 PRO HT.
More Versatile and Stable than Ever Before
For the very first time, the INTAMSYS FUNMAT PRO 610 HT features dual extruders which operate in a large 24" X 20" X 20" (610mm x 508mm x 508mm) allowing for printing support and multiple Functional Materials (PEEK, PEKK, PPSU, ULTEM, ABS, PC and much more). A linear guide and a high-performance oriental motor ensure high speed and high precision.
Uncompromising Level of Detail
Regarding the X and Y axis, the movement is directly entrusted to the full metal chassis which provides a solid rigid enclosure for the core internal mechanics. A metal casing with glass windows and a fully insulated chamber help to maintain a consistent printing environment. For improved printing performance, the INTAMSYS FUNMAT PRO 610 HT has a controlled actively heated chamber (300°C/572°F) and a heated aluminum plate bed (300°C/572°F). This allows for rapid and extremely accurate positioning with noticeable results in terms of resolution and speed of production of materials previously unavailable to the 3D printing community.
New All Metal Hot End
It represents the heart of the filament deposition technology. INTAMSYS has completely redesigned the extruder, to conduct the heat in the exact spot where the material softens, enabling its dissipation throughout the rest of the surface. Innovative design ensures that the filament is channeled directly through the hotend helping to prevent breakage, seepage, and inaccuracy.
Wide Selection of Industry Defined Materials
INTAMSYS FUNMAT PRO 610 HT is designed to allow the use of the latest in material technology. With our eight-step quality control process and rigorous in-house testing, you can rest assured that your part will work every time. With options such as PEEK, the industry standard for metal replacement, with it's high tensile strength and resistance to chemical corrosion as well as many other high-performance materials. INTAMSYS' ongoing research and development partnership program, focusing on everything from strategic support and advanced materials research, to complex parts design and production, is a partnership program that complements our partners’ in-house capabilities with INTAMSYS’ state-of-the-art research facilities, technologies and expertise in high-performance functional materials 3D printing.
A Better Eye on Production
The integrated non-conductive touchscreen allows you to control the print even while wearing the hot glove. With the Filament breakage alert, which monitors the filament as it is fed through the hotend and immediately pauses the print if an error occurs, and built-in camera, that allows remote monitoring via an App on your smartphone, you can control all aspects of your model and ensure its efficient production.
Powerful and Easy to Use Software
The INTAMSUITE software contains everything you need to begin making parts on your new 3D printer. Import and manipulate geometry, repair models, generate G-code instructions, verify tool paths, manually control your machine, and print parts all from the same program. It provides detailed print preview capabilities allowing for a thorough analysis of a model prior to 3D printing. An independent sensor blocks the machine in case of emergency.
